1234AC

SAM™ Studio Monitor

The 1234AC is a smart main studio monitor for use in demanding film and post production work, where perf screen or hi-res LED displays are employed.

Smart Active Monitoring (SAM™) and GLM™ calibration technology

Optimised Amplifiers


SPL

125 dB

Frequency Response

29 Hz - 21 kHz (-6 dB)

Dimensions

H 489 x W 1210 x D 412 mm, (view in inches)

Make accurate decisions

Designed for mixing stages and large control rooms, the directivity and SPL capability of the 1234AC is compatible with typical screen channels in commercial cinema, but with the higher performance required for professional monitoring. The 1234AC may be used in either horizontal or vertical orientation - thereby tailoring the LF directivity to both the room and the monitor placement - while precise on and off axis imaging allows you to make accurate mix decisions even when sitting outside the narrow sweet spot of most studio monitors.

Optimise for your room

The 1234AC tightly integrates with our GLM calibration application, which compensates for detrimental room influence, perf screen effects and delay, regardless of whether you work with traditional or large immersive formats. GLM also builds complete monitoring systems, so that the 1234AC can easily be combined with other types of Genelec smart monitors and subwoofers to deliver truly optimised reference monitoring - and material that translates perfectly.

Genelec

1234AC SAM™ Studio Monitor

Color options:
Package contains:

1 x 1234AC monitor
1 x individually calibrated RAM-XL
amplifier unit
1 x mains cable 1,8 m
1 x RJ45 cable 5 m
1 x RJ45 cable 10 m
2 x 4-pole Speakon cable 10 m
1 x operating manual

Warranty:
2 years parts-and-labour (extended to 5 years with free registration).

GLM Calibration:
Requires free GLM software and either our 9320A SAM™ Reference Controller or GLM Calibration Kit device (both sold separately) for calibration.

Genelec

1234AC SAM™ Studio Monitor

Color options:

Technical Specifications

SPL

125 dB

Amplifier Power

2 X 750 W Bass (Class D) + 400 W Midrange (Class D) + 250 W Treble (Class D)

Frequency Response

29 Hz - 21 kHz ("-6 dB")

Accuracy of Frequency Response

± 2 dB (34 Hz - 20 kHz)

Driver Dimensions

2 x 305 mm Bass + 125 mm Midrange + 25 mm Treble (view in inches)

Dimensions

H 489 x W 1210 x D 412 mm, (view in inches)

Weight

79.5 kg / 175.3 lb

Connections

1 x XLR Analog Input

1 x XLR AES/EBU Input

1 x XLR AES/EBU Output

2 x RJ45 Control

Key Technologies

Smart Active Monitoring (SAM™) and GLM™ calibration technology

Optimised Amplifiers

Intelligent Signal Sensing (ISS™) Technology

Directivity Control Waveguide (DCW™) Technology

Active Crossovers

Protection Circuitry
